48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper

48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper
48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper

Large Image :  48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper

Product Details:
Place of Origin: China
Brand Name: SED Pharma
Certification: CE
Model Number: SED-48S
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wooden Case
Delivery Time: 35 days after receiving the deposit
Payment Terms: T/T,L/C,MoneyGram,Cash
Supply Ability: 30 Sets Per Month

48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper

Description
Name: Energy Saving Automatic 48 Channel Gelatin Capsule Counting Machine Hopper Volume: 100L
Capacity: 10-120bottles/min Compressed Air: 06Mpa
Machine Weight: 900KGS Dimension: 2160*1560*1700mm
Machine Speed: 2-9999 Pcs /min Warranty: 1 Year
Highlight:

48 channel capsule counting machine

,

high speed capsule counting machine 120bottles/min

,

large hopper capsule counting machine 100L

Automatic 48 Channel Gummy Bear Soft Candy Counter Soft Capsule Bottling Machine
Energy Saving Automatic 48 Channel Gelatin Capsule Counting Machine
Technical Parameters of Tablet Counter Machine
Model name SED-48S
Product name Energy Saving Automatic 48 Channel Gelatin Capsule Counting Machine
Application
  • Hard capsule (000-5#)
  • Soft Gelatin capsule
  • Pills, tablets
  • Chewing gum, other solid object (Diameter: 5.5-22mm)
Hopper Volume 100L
Capacity 10-120 bottles/min
Filling Quantity 2-9999 pcs/bottle (adjustable)
Power supply 220v 50HZ 1.6KW
Compressed air 0.6Mpa 5L/min
Bottle Size Diameter: ≤50mm Height: ≤180mm
Counting Size Pills with diameter of 22 or less are compatible with 000-5 capsules soft capsules with diameters of 3.5-22 plain tablets special-shaped tablets sugar-coated tablets
Machine Weight 900kg
Machine Size L × W × H (mm) 2160*1560*1700mm
Main Features of Tablet Counter Machine
  • Compatibility, high accuracy, wide application and use of the Company's original anti-dust photoelectric detection of high technology, can count Tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pill count to bottling
  • Vibratory cutting drugs do not damage
  • High degree of intelligence, with no bottle is not the number of self-fault detection alarm and many other control functions
  • Compact structure, stability and durability, and no regular replacement parts, small footprint, the use of low-cost
  • To facilitate the replacement of species, can automatically take-off and landing, demolition cleared without any tools, convenient and quick
Working Principle of Tablet Counter Machine
Electronic counting machines are our company's star products, which is a stable reliable electronic products that was successfully developed through repeated experiment after a long time research. Its core part and control system adopt imported original accessories. It mainly consists of such structures as hopper, vibration transmission, photoelectric sensor, dust storage box, human-computer interface.
Product Show of Tablet Counter Machine
48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper 0
48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper 1
48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper 2
48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper 3
Application of Tablet Counter Machine
Suitable for a wide range of granules, such as tablets, capsules, gels, beans, hardwares, candy, etc. 0-5# capsules, soft capsules, φ5.5-12 normal tablets, special shape tablets, coating tablets and other solid granules
48 Channel Capsule Counting Machine 10-120bottles/min 100L Hopper 4
