Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min

Large Image : Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min

Product Details:

Model Number:	SED-8SP

Contact Now

Automatic Capsule Counting Machine 16L Hopper 10-45 Bottles/Min

Description

Hopper Volume:	16L	Capacity:	10-45 Bottles/min
10-45 Bottles/min:	2-9999pcs/bottle (adjustable)	Bottle Size:	Diameter ≤100mm,Height ≤180mm
Conveyor Belt Width:	114mm	Compressed Air:	0.6Mpa 5L/min
Voltage:	220V/50HZ/60HZ	Overall Dimension (LWH):	192013601730mm
Highlight:	automatic capsule counting machine with 16L hopper , capsule counting machine 10-45 bottles per minute , high-speed automatic capsule counter

Automatic Capsule Tablet Counting Machine for Candy Pill Packing

Machine Introduction

This updated counting machine features quick material interchangeability for multiple applications. Designed with high-speed operation and efficient hygiene functions, it significantly reduces labor requirements. The machine offers fast and easy installation to maximize productivity, particularly suited for counting and filling soft candies and sticky-textured materials.

Working Principle

The bottle blocking device on the conveyor belt positions containers for filling. Materials enter the counting device through vibrating corrugated plates, where photoelectric sensors perform accurate counting before loading into bottles at the filling position.

Technical Parameters

Model Name	SED-8SP
Application	Hard capsule (000-5#), Soft Gelatin capsule, Pills, Chewing gum, tablet, and solid objects (Diameter: 5.5-22mm)
Hopper Volume	16L
Capacity	10-45 bottles/min
Filling Quantity	2-9999pcs/bottle (adjustable)
Bottle Size	Diameter ≤100mm, Height ≤180mm
Conveyor Belt Width	114mm
Compressed Air	0.6Mpa, 5L/min
Voltage	220V/50HZ/60HZ
Overall Dimension (LWH)	192013601730mm

Key Features

3-stage adjustable vibration: Precisely controls capsule output speed
Strong compatibility: Counts tablets (including special-shaped), capsules, soft capsules (transparent/opaque), and pills
Quick material change: No mold changes required when switching counting objects
8-channel vibration: Ensures even material discharge without damage
Hygienic design: Easy cleaning with removable vibration plates
Anti-dust system: Patented photoelectric sensor technology maintains stable operation in dusty conditions
Precision counting: Photoelectric sensors ensure accurate bulk counting
Smart detection: Includes no-bottle-no-counting, self-diagnosis, and jam detection functions
User-friendly: Touch screen interface for simplified operation
