360° High Speed Automatic Capsule Appearance Inspection Machine GMP Compliant

Large Image : 360° High Speed Automatic Capsule Appearance Inspection Machine GMP Compliant

Product Details:

Place of Origin:	China
Brand Name:	SED Pharma
Certification:	CE
Model Number:	SED-JSJT-E

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	Wooden Case
Delivery Time:	50-60 Days after receiving the deposit
Payment Terms:	T/T,L/C,MoneyGram,Cash
Supply Ability:	30 Sets per month

Contact Now

360° High Speed Automatic Capsule Appearance Inspection Machine GMP Compliant

Description

Name:	360° High-Speed Automatic Capsule Appearance Inspection Machine	Applicabl:	00#~5#, Dosage Forms Other Than Standard Specifications Shall Be Subject To The Test Results
Inspection Item:	Stains, Scratches, Foreign Object Attachments, Punctures, Dents, Anomalies, Discoloration, Etc	Detection Range:	360 Degree All-round
Accuracy:	0.05 MM, Adjustable Accuracy	Operation Screen:	Touch Screen (18.5 Inches)
Power Supply:	380 V ; 50Hz	Key Word:	Capsule Inspection Machine, 360° Capsule Inspection Equipment
Highlight:	360° visual inspection machine , high accuracy visual inspection equipment , GMP Compliant visual inspection equipment

Product Overview of 360° High-Speed Automatic Capsule Appearance Inspection Machine

The SED-JSJT-E series 360° High-Speed Automatic Capsule Appearance Inspection Machine is a high-precision, fully automated capsule defect detection system designed specifically for the pharmaceutical industry.

This equipment utilizes advanced imaging technology to achieve a 360° scan of the capsule surface without blind spots, effectively identifying minute defects that affect product quality.

Product Parameters of 360° High-Speed Automatic Capsule Appearance Inspection Machine

Model	SED-12-1440JSJT-E	SED-30-3600JSJT-E	SED-60-7200JSJT-E
Channel	12 channel	30 channel	60 channel
Detection Speed	86,400 pcs/hour	216,000 pcs/hour	432,000 pcs/hour
Applicable	00#~5#, dosage forms other than standard specifications shall be subject to the test results
Inspection Item	Stains, scratches, foreign object attachments, punctures, dents, anomalies, discoloration, etc
Detection Range	360 degree all-round
Accuracy	0.05 MM, Adjustable accuracy
Operation Screen	Touch screen (18.5 inches)
Power Supply	380 V ; 50Hz
Power	3 KW	3 KW	4 KW
Environment	Temperature: 10-30°C; Humidity: 30-70%
Size	9259501400 MM	11109501400 MM	126310901400 MM
Weight	500 KG	600 KG	900 KG

Feature of 360° High-Speed Automatic Capsule Appearance Inspection Machine

360° All-Around Inspection: Completely eliminates blind spots, covering the entire surface of the capsule cap, body, and junctions.
Compatible with All Models: Compatible with standard capsules from 00# to 5# (supports custom testing).
AI Intelligent Recognition: Efficiently detects stains, scratches, foreign objects, holes, dents, color abnormalities, etc.
Touchscreen Control: Equipped with an 18.5-inch extra-large touchscreen for real-time monitoring of test data and intuitive operation.
Precision Control: Accuracy up to 0.05 mm, meeting extremely stringent GMP pharmaceutical standards.

Show of 360° High-Speed Automatic Capsule Appearance Inspection Machine

360° High Speed Automatic Capsule Appearance Inspection Machine GMP Compliant 0
