Automatic Induction Tube Filling And Sealing Machine Aluminum Foil Sealing Machines

Automatic Induction Tube Filling And Sealing Machine Aluminum Foil Sealing Machines

  • High Light

    Electromagnetic Tube Filling And Sealing Machine

    ,

    Aluminum Tube Filling And Sealing Machine

    ,

    120bottles/min Tube Filling And Sealing Machine

  • Name
    Automatic Induction Tube Filling And Sealing Machine Aluminum Foil Sealing Machines
  • Bottle Size
    20-300ml
  • Output
    50-120bottles/min
  • Diameter Of Caps
    Smaller Than 60mm
  • Height Of Bottle
    220mm
  • Power Supply
    220V 60Hz
  • 220V 60Hz
    2Kw
  • Overall Dimensions
    1300*780*1750mm
  • Place of Origin
    China
  • Brand Name
    SED Pharma
  • Certification
    CE
  • Model Number
    SED-LF
  • Minimum Order Quantity
    >=1 Pieces
  • Price
    $6,000.00/ Piece
  • Packaging Details
    Export standard packing
  • Delivery Time
    Est. Time(days)-15-To be negotiated
  • Payment Terms
    T/T,L/C, MoneyGram,Cash
  • Supply Ability
    30 Piece/Pieces per Month

Automatic Induction Tube Filling And Sealing Machine Aluminum Foil Sealing Machines

Automatic Induction Tube Filling And Sealing Machine Aluminum Foil Sealing Machines



Bottle Size 20-300ml
Output 50-120bottles/min
Diameter of caps Smaller than 60mm
Height of bottle 220mm
Power Supply 220V 60Hz
Power 2Kw
Overall Dimensions 1300*780*1750mm



Product description



Intermediate frequency power supply of the machine makes effective output power great and output current adjustable. It also auto tracks change of current load and makes adjustment in time. If there is no bottle in the specified position, it will stop automatically to save electric power.


The machine is available for various bottles. The special sealing induction plate is completely shielded without electromagnetic pollution and its safety is superior to high-frequency power supply.


Coding system of the machine adopts built-in water circulation to save water consumption and reduce water pollution; it also has pressurizing system which features good cooling conditions, short sticking time, firm sealing and high stability.


Even if the mouth of the bottle is moist with many kinds of liquid, the machine still seals perfectly.


If water stop, The machine will sound alarm. Besides, some mechanism protects the machine from being damaged by over current, over voltage and under voltage. And it also has functions of continuous counting and automatic rejection of caps without aluminum foil.


The product confirms to the requirements of GMP.

Theory

According to the principle that metal objects generate huge eddy current and heat under the action of high-frequency
electromagnetic field, the machine fuses the adhesive film of the lower layer of aluminum foil and fuses with bottle mouth through electromagnetic induction to achieve continuous and rapid non-contact sealing.
