Product Details:
|
| Name: | Small Spray Drying Machine Pharmaceutical Machine With Centrifuge Nozzle | Precision Of Temp Dryer Time: | ±1 1.0 ~ 1.5 |
|---|---|---|---|
| Nozzle Size: | 0.5/0.7/0.75/1.0/1.5/2.0 | Heat Source: | Electric |
| Material: | Stainless Steel | Key Word: | Spray Drying Machine |
| High Light: | dryers used in pharmaceutical industry,fluid bed dryer granulator |
||
Small Spray Drying Machine Pharmaceutical Machine With Centrifuge Nozzle
Product Description of Sprying Drying Machine
This Lab spray dryer has Stainless steel shell and arc corner design.Equip with imported Schneider electrical components,PLC control system,self-priming peristaltic pump and oil-free air compressor,is suitable for producing solid powder or particle products from liquid materials drying,such as emulsion, suspending liquid, liquor and so on.
Product Parameters of Sprying Drying Machine
| Item | Unit | TP-S15 | TP-S50 | TP-S100 | |
| Max capacity | ml/h | 1500-2000 | 5000 | 10000 | |
| Temperature range of inlet air | ℃ | 40℃ ~ 300℃ | 140°C ~ 300°C Adjustable | 50°C ~ 300°C | |
| Temperature range of outlet air | ℃ | 80℃ ~ 90℃ | 80°C ~ 90°C | 80°C ~ 90°C | |
| Spray system | / | Two-fluid nozzle | Centrifugal nozzle | Centrifugal nozzle | |
| Precision of temp | ℃ | ±1 | |||
| Dryer time | S | 1.0 ~ 1.5 | |||
| Speed of squirt pump | ml/h | 50 ~ 2000 | 5000 | 10000 | |
| Nozzle size | mm | 0.5/0.7/0.75/1.0/1.5/2.0 | |||
| Spray direction | / | Downwards co-current | |||
| Heater Power | / | 3500W | 6800W | 12000W | |
| Total power | / | 4500W 220V | 9000W 380V | 22000W 380V | |
| Heat source | / | Electric | |||
| Air compressor | / | Built-in oil-free air compressor | |||
| Dried powder restoring rate | % | ≥95 | ≥98 | ||
| Dimension | mm | 940*850*1500 | 1800*930*2200 | 2500*1600*2800 | |
| Maximum moisture evaporation | Kg/h | 2 | 5 | 10 | |
Advantages of Sprying Drying Machine
1. Stainless steel material, arc corner design and polyester powder coated shell, prevents corrosion of acidity and alkaline air effectively.
2. Imported Schneider electrical components which is more stability.
3. PLC control system, make your research more easier and efficient.
4. Build in oil-free air compressor, without any noise.
5. Self-priming peristaltic pump, avoid secondary pollution, make sure whole process conducted steady and smoothly.
6. Narrow size distribution, more than 95% of the dry powders are in the same range of particles.
7. Innovative tower wall purging device, improves the material recycling rate.
8. High speed of drying, after spraying of the material liquid, the surface area of material will be increased greatly, make your research more efficient.
9. In the hot-air flow, 95%~98% of water can be evaporated at a moment. You can finish material drying only in several seconds.
10. Especially suitable for drying the heat sensitive materials, after drying, there's no need for smashing and sorting, so as to reduce the operation procedures and save your time.
Products Show of Sprying Drying Machine
