Product Details:
|
| Name: | Pharmacy Use Single Phase Type Capsule Polishing Machine Power Supply 220V,50Hz,2A,Single-Phase | Power Supply: | 220V,50Hz,2A,Single-phase |
|---|---|---|---|
| Weight: | 40kgs | Compressed Air: | 0.25m3/mn 0.3mpa |
| Package Size: | 870x600x720mm | Overall Dimension: | 800x550x1000mm |
| High Light: | capsule filling device,capsule filling equipment,4000Pcs/Min Capsule Polishing Machine |
||
Pharmacy Use Single Phase Type Capsule Polishing Machine 4000 Pcs/min
Product Description of Capsule Polishing Machine:
JPG Series Capsule Polisher is an advanced capsule polishing machine with filtrating function. The Whole machine is made from stainless steel; fast connection of roller bruch leads to disassemble easily and clean thoroughly; frequency inverter
controls the speed of the motor, so it can bear big start up force and run very stable and reliable. It is not only applied to polishing capsule, tablet and eliminating the static electricity, but also applied to rejecting empty capsule, little dosage capsule, separated capsules and fragment. This machine is suitable for all sizes of capsules.
Technical Parameters of Capsule Polishing Machine :
| capacity | 4000 Pcs/min |
| Power supply | 220V,50Hz,2A,Single-phase |
| GW | 60kg |
| Net weight | 40Kg |
| Negative | 2.7m3/mn -0.014mpa |
| Compressed air | 0.25m3/mn 0.3mpa |
| shape(LxWxH) | 800x550x1000(mm) |
| Package Size(LxWxH) | 870x600x720(mm) |
Product Show of Capsule Polishing Machine
Features of Capsule Polishing Machine
1. Capsules and tablets can be polished, and empty shells and broken capsules can be removed at the same time;
2. The negative pressure type waste removal device is adopted, which has no pollution to the environment;
3. The parts in contact with medicines are made of stainless steel, and the sanitary conditions of the equipment meet the GMP standard;
4. It has the characteristics of novel mechanism, simple operation, easy cleaning, high polishing efficiency and good cleanliness.
Precautions for use
1. No-load operation for no less than 10 minutes;
2. When shutting down, no capsules should be accumulated in the polishing cylinder to prevent waste;
3. After shutdown, the polishing cylinder, brush, powder receiving tray and entrance and exit should be cleaned up.
Application of Capsule Polishing Machine
