4 KW Corrosion Resistant Double Press Automatic Rotary Salt Tablet Press Machine With Chrome Treated Turret

4 KW Corrosion Resistant Double Press Automatic Rotary Salt Tablet Press Machine With Chrome Treated Turret

  • High Light

    machinery for pharmaceutical industry

    ,

    equipment for pharmaceutical manufacturing

  • Name
    4 KW Corrosion Resistant Double Press Automatic Rotary Salt Tablet Press Machine With Chrome Treated Turret
  • Capacity
    87000 Tablets Per Hour
  • Power Of The Motor
    4 KW
  • Maximum Compression
    100KN
  • Max. Diameter Of Tablet To Be Produced
    25mm
  • Max. Thickness Of Tablet
    17mm
  • Rotary Speed Of The Turret
    20-25rpm
  • Weight
    1950kgs
  • Place of Origin
    China
  • Brand Name
    SED Pharma
  • Certification
    CE
  • Model Number
    SED420-29Y
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiable
  • Packaging Details
    Wooden Case
  • Delivery Time
    30 Days after receiving the deposit
  • Payment Terms
    T/T,L/C, MoneyGram,Cash
  • Supply Ability
    30 Sets Per Month

4 KW Corrosion Resistant Double Press Automatic Rotary Salt Tablet Press Machine With Chrome Treated Turret

4 KW Corrosion Resistant Double Press Automatic Rotary Salt Tablet Press Machine With Chrome Treated Turret



Stations (unit) 29
Maximum compression (KN) 100
Max. Diameter of tablet to be produced (mm) 25
Max. Filling depth (mm) 36
Max. Thickness of tablet (mm) 17
Power of the motor 4 kw
Weight 1950kgs
Rotary speed of the turret (rpm) 20-25
Capacity of the tablets 87000 Tablets per hour
Dimension 1240×980×1650 mm



Performance

This machine is a double press automatic rotation for shape-pressing equipment, which have the function of press the grain material or powders to be round or irregular shape tablets, such as candy, calcium tablets double-sides with letter printing and etc.



which widely suitable for the Industries of pharmaceutical, Chemical, Foodstuff, Plastic Electronic, Powder Metallurgy and so on.



Main Features

1. It is adopts the import Frequency Timing with Electromagnetism Clutch.



2. The system of Hydraulic Pressure keep the working pressure under steady, when the pressure over-loading, it will be stopped the machine automatically.



3. Driving system is equipped with oil box and running under oil, easy for heat dissipation and wear-resistance.



4. It is equipped with Dust Collector as well, which avoid the dust emission, and recycle to save dust
