|Station:||23 Punch Stations||Capacity For Single Layer Tablet:||85,000 Tablets Per Hour|
|Capacity For Double Layer Tablet:||42,500 Tablets Per Hour||Max. Tablet Diameter:||28mm|
|Max.Tablet Thickness:||13mm||Max. Filling Depth:||20mm|
High Quality Rotary Tablet Pressing Machine For Double Layer Tablet Pressing,Duo Color Tablet Pressing
This equipment is a high-tech mechanical and electrical product developed by our company on the basis of years of research and development of automated product inspection. It can suppress all kinds of conventional wafers and other special-shaped tablets (including double-sided printing). It is the best choice for pharmaceutical, chemical, food, plastics, electronics and other production enterprises.
1. It is equipped with Organic-glass perspective window for tablet producing observation. Each perspective window could be fully opened and easy for cleaning and maintenance.
2. It is adopts the import Frequency Timing with Electromagnetism Clutch.
3. Driving system is equipped with oil box and running under oil, easy for heat dissipation and wear-resistance.
4. It is equipped with Dust Collector as well, which avoid the dust emission, and recycle to save dust
Main Technical Data
|Maximum compression (KN)||80|
|Max. Diameter of tablet to be produced (mm)||28|
|Max. Filling depth (mm)||20|
|Max. Thickness of tablet (mm)||13|
|Thickness of the die (mm)||22|
|The diameter of the circle of the central pitch of upper &lower punches on the turret||320mm|
|Rotary speed of the turret (rpm)||14-30rpm|
|Capacity of the tablets (max ten thousand tablets/hour)||
85,000 Tablets (Mono color)
42,500 Tablets(Duo color)
