Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet

Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet
Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet

Large Image :  Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet

Product Details:
Place of Origin: China
Brand Name: SED Pharma
Certification: CE
Model Number: SED-420-27Y-D
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wooden Case
Delivery Time: 30 Days after receiving the deposit
Payment Terms: T/T,L/C,MoneyGram,Cash
Supply Ability: 30 Sets Per Month
Contact Now

Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet

Description
Name: Rotary Salt Tablet Press Machine With Hydraulic Pressing System Working Capacity: 58000 Pcs Per Hour
Max.Pressure: 80KN Max.Filling Depth: 25mm
Max.Pressing Diameter: 18mm Max.Thickness Of Tablet: 8mm
Turret Speed: 0-18rpm Power Supply: 380V 50HZ Three Phase
Material: Stainless Steel Key Word: Tablet Press Machine
Highlight:

tablet compression machine

,

pill press machine

Rotary Salt Tablet Press Machine With Hydraulic Pressing System
Performance of Tablet Press Machine
The SED-420-27Y-D tablet press machine is an automatic double-sided rotary tablet press designed for pharmaceuticals, chemicals, food, and electronics industries. It features a fully enclosed stainless steel body compliant with GMP standards, capable of producing round, irregular, and double-layer tablets with high efficiency and ease of operation.
Main Technical Data of Tablet Press Machine
Item SED-420-27Y-D SED-420-29Y-D SED-420-31Y-D
Number of Dies 27 29 31
Max. Pressure (kN) 80 80 80
Max. Tablet Diameter (mm) 25 24 22
Max. Fill Depth (mm) 18 15 15
Max. Tablet Thickness (mm) 8 7 6
Turret Speed (rpm) 0-18 0-30 0-30
Production Capacity (pcs/h) 58,000 104,400 111,600
Motor Power (kW) 5.5 3 3
Dimensions (mm) 1230×950×1670 1230×950×1670 1230×950×1670
Net Weight (kg) 1700 1700 1700
Main Features of Tablet Press Machine
  • Fully Enclosed Stainless Steel Body: 304 stainless steel structure prevents cross-contamination and allows easy cleaning.
  • Transparent Operation: High-visibility organic glass door enables real-time monitoring and can be fully opened for cleaning.
  • Variable Speed Control: Turret speed is adjustable from 0 to 18 rpm to match production needs.
  • Intelligent Control Panel: Equipped with touch keys and a digital display for monitoring speed, output, and operational status.
  • Sealed Transmission System: Enclosed in an oil tank for effective lubrication, reducing noise and wear.
  • Built-in Dust Collector: Captures dust during compression for a cleaner working environment.
  • Double-Layer Tablet Capability: Easily configured for two-layer tablets (note: output is halved in this mode).
Application of Tablet Press Machine
Round, irregular (e.g., oval, square, capsule), and double-layer tablets.
Rotary Tablet Press Machine with 25mm Max Filling Depth 18mm Max Pressing Diameter and 8mm Max Thickness of Tablet 0
Why Choose Us?
High Output: Up to 58,000 tablets per hour
Flexible Tooling: Easy die changeover for multiple tablet shapes
GMP-Compliant Design: Enclosed structure + dust collection for clean production
Robust & Reliable: Premium materials and branded components for long service life
User-Friendly Operation: Touch interface and digital display for easy control
